MOOTTL系列液压螺母主要用于连接件的无键连接，其工作原理是利用超高压油在轴上产生一个推力和轴套上产生一个张力，使轴和轴套受力均匀的连接在一起。
l 有轴向和径向注油两种方式
l 压力均匀分布于压环
l 标准工作压力100Mpa
使用范围：
l 安装及拆卸轴承；
l 安装及拆卸螺旋桨、舵瓦等；
l 拆卸高压的接合面，如火车轮、联轴器、飞轮及齿轮等；
主要技术参数：
|
型号 |
螺栓规格 |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
E (mm) |
行程(mm) |
面积 mm2 |
重量 (kg) |
|
THN 050 |
M50×1.5 |
50.5 |
104 |
114 |
38 |
4 |
5 |
2900 |
2.70 |
|
THN055 |
M55×2 |
55.5 |
109 |
120 |
38 |
4 |
5 |
3150 |
2.75 |
|
THN060 |
M60×2 |
60.5 |
115 |
125 |
38 |
5 |
5 |
3300 |
2.80 |
|
THN065 |
M65×2 |
65.5 |
121 |
130 |
38 |
5 |
5 |
3600 |
3.00 |
|
THN070 |
M70×2 |
70.5 |
127 |
135 |
38 |
5 |
5 |
3800 |
3.20 |
|
THN075 |
M75×2 |
75.5 |
132 |
140 |
38 |
5 |
5 |
4000 |
3.40 |
|
THN080 |
M80×2 |
80.5 |
137 |
146 |
38 |
5 |
5 |
4200 |
3.70 |
|
THN085 |
M85×2 |
85.5 |
142 |
150 |
38 |
5 |
5 |
4400 |
3.75 |
|
THN090 |
M90×2 |
90.5 |
147 |
156 |
38 |
5 |
5 |
4700 |
4.00 |
|
THN095 |
M95×2 |
95.5 |
153 |
162 |
38 |
5 |
5 |
4900 |
4.30 |
|
THN100 |
M100×2 |
100.5 |
158 |
166 |
38 |
6 |
5 |
5100 |
4.40 |
|
THN105 |
M105×2 |
105.5 |
163 |
172 |
38 |
6 |
5 |
5300 |
4.65 |
|
THN110 |
M110×2 |
110.5 |
169 |
178 |
38 |
6 |
5 |
5600 |
4.95 |
|
THN115 |
M115×2 |
115.5 |
174 |
182 |
38 |
6 |
5 |
5800 |
5.00 |
|
THN120 |
M120×2 |
120.5 |
179 |
188 |
38 |
6 |
5 |
6000 |
5.25 |
|
THN125 |
M125×2 |
125.5 |
184 |
192 |
38 |
6 |
5 |
6200 |
5.35 |
|
THN130 |
M130×2 |
130.5 |
190 |
198 |
38 |
6 |
5 |
6400 |
5.65 |
|
THN135 |
M135×2 |
135.5 |
195 |
204 |
38 |
6 |
5 |
6600 |
5.90 |
|
THN140 |
M140×2 |
140.5 |
200 |
208 |
38 |
7 |
5 |
6800 |
6.00 |
|
THN145 |
M145×2 |
145.5 |
206 |
214 |
39 |
7 |
5 |
7300 |
6.50 |
|
THN150 |
M150×2 |
150.5 |
211 |
220 |
39 |
7 |
5 |
7500 |
6.60 |
|
THN155 |
M155×3 |
155.5 |
218 |
226 |
39 |
7 |
5 |
8100 |
6.95 |
|
THN160 |
M160×3 |
160.5 |
224 |
232 |
40 |
7 |
6 |
8600 |
7.60 |
|
THN165 |
M165×3 |
165.5 |
229 |
238 |
40 |
7 |
6 |
8900 |
7.90 |
|
THN170 |
M170×3 |
170.5 |
235 |
244 |
41 |
7 |
6 |
9400 |
8.40 |
|
THN180 |
M180×3 |
180.5 |
247 |
256 |
41 |
7 |
6 |
10300 |
9.15 |
|
THN1190 |
M190×3 |
191 |
259 |
270 |
42 |
8 |
7 |
11500 |
10.5 |
|
THN200 |
M200×3 |
201 |
271 |
282 |
43 |
8 |
8 |
12500 |
11.5 |
|
THN205 |
Tr205×4 |
207 |
276 |
288 |
43 |
8 |
8 |
12800 |
12.0 |
|
THN210 |
Tr210×4 |
212 |
282 |
294 |
44 |
8 |
9 |
13400 |
12.5 |
|
THN215 |
Tr215×4 |
217 |
287 |
300 |
44 |
8 |
9 |
13700 |
13.0 |
|
THN220 |
Tr220×4 |
222 |
293 |
306 |
44 |
8 |
9 |
14400 |
13.5 |
|
THN225 |
Tr225×4 |
227 |
300 |
312 |
45 |
8 |
9 |
15200 |
14.5 |
|
THN230 |
Tr230×4 |
232 |
305 |
318 |
45 |
8 |
9 |
15500 |
14.5 |
|
THN235 |
Tr235×4 |
237 |
311 |
326 |
46 |
8 |
10 |
16200 |
16.0 |
|
THN240 |
Tr240×4 |
242 |
316 |
330 |
46 |
9 |
10 |
16500 |
16.0 |
|
THN250 |
Tr250×4 |
252 |
329 |
342 |
46 |
9 |
10 |
17600 |
17.5 |
|
THN260 |
Tr260×4 |
262 |
341 |
356 |
47 |
9 |
11 |
18800 |
19.5 |
|
THN270 |
Tr270×4 |
272 |
352 |
368 |
48 |
9 |
12 |
19800 |
20.5 |
|
THN280 |
Tr280×4 |
282 |
363 |
380 |
49 |
9 |
12 |
21100 |
22.0 |
|
THN290 |
Tr290×4 |
292 |
375 |
390 |
49 |
9 |
13 |
22400 |
22.5 |
|
THN300 |
Tr300×4 |
302 |
386 |
404 |
51 |
10 |
14 |
23600 |
25.5 |
|
THN310 |
Tr310×4 |
312 |
397 |
416 |
52 |
10 |
14 |
24900 |
27.0 |
|
THN320 |
Tr320×4 |
322 |
409 |
428 |
53 |
10 |
14 |
26300 |
29.5 |
|
THN330 |
Tr330×4 |
332 |
419 |
438 |
53 |
10 |
14 |
27000 |
30.0 |
|
THN340 |
Tr340×4 |
342 |
430 |
450 |
54 |
10 |
14 |
28400 |
31.5 |
|
THN345 |
Tr345×4 |
347 |
436 |
456 |
54 |
10 |
14 |
29400 |
32.5 |
|
THN350 |
Tr350×4 |
352 |
442 |
464 |
56 |
10 |
14 |
29900 |
35.0 |
|
THN360 |
Tr360×4 |
362 |
455 |
472 |
56 |
10 |
15 |
31300 |
35.5 |
|
THN360 |
Tr365×4 |
367 |
460 |
482 |
57 |
11 |
15 |
31700 |
38.5 |
|
THN370 |
Tr370×4 |
372 |
466 |
486 |
57 |
11 |
16 |
32800 |
39.0 |
|
THN380 |
Tr380×4 |
382 |
476 |
498 |
58 |
11 |
16 |
33500 |
40.5 |
|
THN385 |
Tr385×4 |
387 |
483 |
504 |
58 |
11 |
16 |
34700 |
41.0 |
|
THN400 |
Tr400×4 |
402 |
499 |
522 |
60 |
11 |
17 |
36700 |
45.5 |
|
THN410 |
Tr410×4 |
412 |
510 |
534 |
61 |
11 |
17 |
38300 |
48.0 |
|
THN420 |
Tr420×4 |
422 |
522 |
546 |
61 |
11 |
17 |
40000 |
50.0 |
|
THN430 |
Tr430×4 |
432 |
532 |
556 |
62 |
11 |
17 |
40800 |
52.5 |
|
THN440 |
Tr440×4 |
442 |
543 |
566 |
62 |
12 |
17 |
42500 |
54.0 |
|
THN450 |
Tr450×4 |
452 |
554 |
580 |
64 |
12 |
17 |
44100 |
57.5 |
|
THN460 |
Tr460×4 |
462 |
565 |
590 |
64 |
12 |
17 |
45100 |
60.0 |
|
THN470 |
Tr470×4 |
472 |
576 |
602 |
65 |
12 |
18 |
46900 |
62.0 |
|
THN480 |
Tr480×4 |
482 |
587 |
612 |
65 |
12 |
19 |
48600 |
63.0 |
|
THN490 |
Tr490×4 |
492 |
597 |
624 |
66 |
12 |
19 |
49500 |
66.0 |
|
THN500 |
Tr500×4 |
502 |
609 |
636 |
67 |
12 |
19 |
51500 |
70.0 |
